Ball Roundness (Sphericity) Test Machine (FH-1352-01)

32 points. 40 points. 30 points. The complete 3D roundness picture — not a single-plane approximation.

The FH-1352-01 measures ball roundness in three-dimensional space, sampling 30–40 points across all panel configurations (8-panel / 18-panel / 32-panel) to calculate the average circumference and maximum radius difference that defines sphericity. A PLC processes multi-point data automatically; the HMI displays average circumference and maximum radius difference to 0.001mm resolution. Clamping force is held below 7N to prevent ball deformation during measurement. Compliant with GB/T 14625.1 for basketballs, footballs, volleyballs, and handballs.

Quick Specs

• Standard: GB/T 14625.1

• Applicable balls: Basketball, football (soccer), volleyball, handball

• Measurement method: 3D multi-point spatial sampling

• Sampling points: 32 (8-panel) / 40 (18-panel) / 30 (32-panel)

• 3-axis intersection point tolerance: ±0.02mm

• Probe repeatability: 0.02mm

• Display accuracy: 0.001mm

• Clamping force: <7N

• Control: PLC + HMI

• Air supply: 0.5MPa

• Power: AC 220V, 5A, 300W

• Dimensions: 830 × 830 × 940mm

• Weight: ~120kg

Table of Contents

1. Why Ball Roundness Requires 3D Multi-Point Measurement

2. Overview of the FH-1352-01 Test Machine

3. Standards Covered: GB/T 14625.1, FIBA, FIFA, FIVB, IHF

4. Measurement Method: Sampling Points by Ball Panel Configuration

5. Design Features of the FH-1352-01

6. Technical Specifications

7. How the FH-1352-01 Measurement Process Works

8. Benefits for Ball Manufacturers and Testing Labs

9. Choosing the Right Ball Roundness Tester

10. Real-World Application Scenarios

11. FAQs for the FH-1352-01

12. Related Testing Equipment

13. Get a Quote from Feihong Machine

Why Ball Roundness Requires 3D Multi-Point Measurement

A sports ball is not round in the way a machined steel sphere is round. It is an assembly of stitched or bonded panels over an inflated bladder — and the roundness of that assembly is determined by the consistency of panel shape, panel placement, seam tension, bladder uniformity, and inflation pressure. Any of these variables can produce a ball that measures acceptable circumference at one meridian and out-of-round at another.

This is why single-plane circumference measurement — wrapping a tape around the ball at one equator — is insufficient for roundness qualification. A ball can pass a single-circumference check while being measurably oblate, prolate, or irregular in the perpendicular plane. In play, non-round balls produce unpredictable bounce trajectories, inconsistent spin behavior, and unequal aerodynamic drag across orientations — all of which affect the game and the athlete's experience.

True roundness — sphericity — requires measuring the ball's surface in three dimensions, at multiple points distributed across its full surface, and calculating the statistical spread of radius values. The larger the maximum radius difference (the gap between the largest and smallest radii measured), the less round the ball. A ball is considered round within specification when its maximum radius difference falls within the tolerance defined by the applicable governing body standard.

GB/T 14625.1 — China's national standard for sports ball roundness measurement — specifies exactly this: a defined number of measurement points, distributed across the full ball surface in a defined pattern, processed to yield average circumference and maximum radius difference. The FH-1352-01 implements this test method for 8-panel, 18-panel, and 32-panel ball constructions.

Overview of the FH-1352-01 Test Machine

The FH-1352-01 is a 3D multi-point ball roundness tester designed to implement the GB/T 14625.1 measurement protocol for basketballs, footballs, volleyballs, and handballs. The ball is held in a low-force pneumatic clamp (<7N — below the threshold that would deform the ball under test) and a probe system traverses the ball's surface in three-dimensional space, sampling the defined number of points per ball construction type.

The PLC collects the probe position data at each sampled point, calculates the average circumference and maximum radius difference across all measured points, and displays both values on the HMI to 0.001mm resolution. The maximum radius difference is the roundness indicator — the smaller it is, the more spherical the ball.

Three sampling configurations are built in, matched to the three most common ball panel constructions in international sports:

• 8-panel construction (e.g., volleyballs, some footballs): 32 sampling points

• 18-panel construction (e.g., traditional footballs): 40 sampling points

• 32-panel construction (e.g., basketballs, some handballs): 30 sampling points

Each configuration is designed so that sampling points are distributed across both seam regions and panel centers — capturing the full surface variation profile, not just the seams or just the panels.

Standards Covered: GB/T 14625.1, FIBA, FIFA, FIVB, IHF

GB/T 14625.1 — Sports Balls: Roundness Test Methods (China)

GB/T 14625.1 is the primary Chinese national standard governing ball roundness (sphericity) test methods for sports balls. It defines:

• The measurement coordinate system (three-axis spatial measurement)

• The number and distribution of measurement points per ball panel configuration

• The calculation method for average circumference and maximum radius difference

• The roundness expression (maximum radius difference as the metric)

• Pass/fail tolerances for each ball sport category

The FH-1352-01 is designed and calibrated to execute the GB/T 14625.1 test protocol. All technical specifications — sampling point counts, 3-axis intersection tolerance, probe repeatability, and display accuracy — are selected to meet or exceed the measurement uncertainty requirements of this standard.

International Governing Body Roundness Requirements

While these governing bodies express roundness requirements in circumference deviation terms rather than maximum radius difference, the two metrics are mathematically related — a maximum radius difference converts directly to a circumference variation via 2π. The FH-1352-01's display of both average circumference and maximum radius difference allows manufacturers to verify compliance against both GB/T 14625.1 (radius difference) and international governing body specifications (circumference deviation) from a single test.

Balls Covered by Construction Type

Measurement Method: Sampling Points by Ball Panel Configuration

The FH-1352-01's measurement approach is fundamentally different from simple circumference measurement — it builds a 3D radius map of the ball's surface.

3D Coordinate Measurement Principle

The machine positions a probe at defined locations on the ball's surface in three-dimensional space, using a three-axis coordinate system with a defined intersection point (the machine's geometric center). The probe contact position at each measurement point gives a radius value relative to this center. After all points are sampled, the PLC calculates:

Average circumference = 2π × (mean radius across all sampled points) Maximum radius difference = (largest sampled radius) − (smallest sampled radius)

The maximum radius difference is the roundness indicator: it quantifies how much the ball deviates from a perfect sphere in which all radii would be equal.

Why Point Count Differs by Panel Configuration

Each panel configuration has a different surface geometry — the seam pattern distributes differently across the ball surface depending on how many panels are used. The sampling point counts (32, 40, 30) are calibrated to ensure that:

• Points are distributed across both seam regions and panel centers — capturing the full range of surface variation

• No panel is systematically under-sampled relative to others

• The point distribution gives statistically representative coverage of the full sphere

More panels (32-panel basketball) do not necessarily require more points than fewer panels (8-panel volleyball) — it depends on the seam pattern geometry and how it maps onto the sphere.

3-Axis Intersection Tolerance: ±0.02mm

The three measurement axes of the machine intersect at a defined center point. The tolerance on this intersection — ±0.02mm — defines the geometric accuracy of the machine's coordinate system. Any error in the intersection point introduces a systematic offset in all radius measurements. At ±0.02mm, the intersection error contributes less than 0.02mm to the maximum radius difference result — smaller than the probe repeatability and well within the measurement uncertainty budget for GB/T 14625.1 compliance.

Design Features of the FH-1352-01

Low-Force Pneumatic Clamping (<7N)

The ball is held by a pneumatic clamping system with clamping force controlled below 7N throughout the measurement. This limit is critical: sports balls are pressurized elastic structures, and any clamping force above the threshold for local surface deformation will distort the ball at the clamp contact points — producing artificially high radius values at those points and inflating the maximum radius difference result. At <7N, the clamping force is below the local deformation threshold for all balls in the applicable size and pressure range, ensuring the ball's natural roundness is measured rather than a clamp-induced distortion.

PLC + HMI Control System

The measurement system uses a PLC (Programmable Logic Controller) for data acquisition and processing — collecting probe position data at each sampling point, calculating average circumference and maximum radius difference, and managing the measurement sequence. The HMI (Human-Machine Interface) panel allows the operator to select the ball configuration (8/18/32-panel), start the measurement, and read results — without requiring a separate PC or specialist operator training.

0.001mm Display Resolution

Results are displayed to 0.001mm (1μm) resolution. For context: a typical sports ball roundness tolerance is in the range of 5–20mm circumference variation — equivalent to approximately 0.8–3.2mm maximum radius difference. At 0.001mm display resolution, the instrument reads the measurement value with 1,000× finer resolution than the pass/fail tolerance, providing a detailed numerical picture of where the ball sits within its specification band rather than just a pass/fail indication.

0.02mm Probe Repeatability

The probe that contacts the ball surface has a repeatability of 0.02mm — meaning that repeated measurements of the same ball under the same conditions will give results that agree to within 0.02mm. This repeatability figure bounds the random measurement uncertainty contribution to the roundness result, ensuring that borderline balls are classified consistently rather than randomly varying between pass and fail on successive measurements.

Automatic Multi-Point Sampling Sequence

The machine automatically sequences through all sampling points for the selected ball configuration — the operator does not manually position the probe at each of 30–40 points. The PLC controls the probe traversal and data capture at each point, ensuring consistent dwell time and contact force at every measurement location.

Technical Specifications of the FH-1352-01

Measurement Performance

Control and Physical

Why These Specifications Matter

• <7N clamping force is the specification that prevents measurement-induced error at the clamp contact points. The 7N limit is derived from the minimum local surface stiffness of a properly inflated sports ball — keeping clamping force below this threshold ensures the ball surface is not deformed at the measurement origin points.

• 0.001mm display resolution vs. 0.02mm probe repeatability: The display resolves 20× finer than the probe's repeatability. This is intentional: reporting results at finer resolution than the measurement uncertainty is useful for trend analysis and process control (detecting drift before it reaches the rejection threshold), even though the absolute accuracy is bounded by the probe's 0.02mm repeatability.

• PLC-based data processing rather than manual calculation eliminates arithmetic error in the average circumference and maximum radius difference calculation — which, across 30–40 data points, is non-trivial to perform manually and prone to transcription errors.

• 30–40 sampling points vs. single circumference measurement: A single circumference tape measurement gives one data point. The FH-1352-01 gives 30–40 radius measurements distributed across the full surface — a 30–40× increase in spatial information that is the difference between knowing that one great circle is within spec and knowing that the full sphere is within spec.

How the FH-1352-01 Measurement Process Works

Step 1: Inflate Ball to Test Pressure

The ball is inflated to the governing body-specified test pressure for its sport and category. Roundness measurement results depend on inflation pressure; measuring at non-standard pressure produces results that are not comparable to the specification reference conditions.

Step 2: Mount Ball in Clamp

The ball is placed in the pneumatic clamp fixture. The clamp closes automatically to the <7N holding force set point — securing the ball in position without local surface deformation.

Step 3: Select Ball Configuration

The operator selects the ball panel configuration on the HMI: 8-panel (32 points), 18-panel (40 points), or 32-panel (30 points). This sets the probe traversal sequence and data collection pattern.

Step 4: Automated Measurement Sequence

The probe system traverses the ball surface automatically, contacting the ball at each of the 30–40 defined measurement points. The PLC records the probe position (radius from center) at each point.

Step 5: PLC Calculation and Display

On completion of the sampling sequence, the PLC calculates:

• Average circumference from the mean radius across all sampled points

• Maximum radius difference from the range of sampled radius values (maximum minus minimum)

Both values are displayed on the HMI to 0.001mm resolution.

Step 6: Pass/Fail Assessment and Recording

The displayed values are compared to the applicable standard or governing body specification limits. Results are recorded for QC documentation, certification submission, or process control data.

Benefits for Ball Manufacturers and Testing Labs

Complete 3D Roundness Picture vs. Single-Meridian Circumference

A tape-measure circumference check tells you one circumference. The FH-1352-01 gives 30–40 radius measurements distributed across the full sphere — the only way to detect oblate, prolate, or irregular roundness deviations that a single great circle measurement would miss entirely.

Dual Output: Both GB/T 14625.1 and International Governing Body Formats

One measurement gives both the Chinese national standard output and the international governing body circumference figure — covering all markets from a single test.

PLC Automation Eliminates Calculation Error

Calculating average circumference and maximum radius difference from 40 manual probe readings introduces arithmetic error and transcription risk. PLC processing is deterministic and error-free — the same 40-point dataset always yields the same result, independent of operator.

Production QC at Volume

The automated probe traversal sequence and HMI interface allow non-specialist operators to run complete 3D roundness measurements with minimal training — making the FH-1352-01 practical for production line QC at volume, not just for specialist lab use.

Choosing the Right Ball Roundness Tester

3D Multi-Point vs. 2D Circumference Measurement

For governing body approval testing and production QC under GB/T 14625.1, 3D multi-point measurement is the required method. 2D circumference measurement (tape or circumference gauge at a single meridian) does not satisfy the standard's measurement protocol and cannot detect out-of-round conditions that lie in a different plane from the measured meridian. Confirm that any tester under consideration uses 3D spatial measurement, not single-plane circumference approximation.

Sampling Point Count — Does It Match Your Ball Construction?

The sampling point pattern must be matched to the ball's panel construction. A machine calibrated for 18-panel football measurement cannot simply be applied to an 8-panel volleyball — the probe traversal geometry is different. Confirm that the machine covers your specific ball construction types.

Probe Repeatability vs. Your Pass/Fail Tolerance

The probe repeatability (0.02mm for the FH-1352-01) determines whether borderline balls near the pass/fail limit will be classified consistently. A probe with 0.1mm repeatability on a pass/fail tolerance of 0.3mm maximum radius difference would misclassify borderline balls on a significant fraction of measurements. Verify that the machine's probe repeatability is appropriately small relative to your tightest roundness tolerance.

Clamping Force Specification

Confirm that the clamping force specification is below the local deformation threshold for your ball type at your specified inflation pressure. A machine that clamps at 20–30N will deform the ball surface at the clamp contact points — producing artificially inflated maximum radius difference values and potentially rejecting balls that are actually within specification.

Real-World Application Scenarios

A basketball manufacturer implementing GB/T 14625.1 compliance testing found through FH-1352-01 production sampling that roundness varied systematically by production shift — balls from the morning shift averaged 1.2mm maximum radius difference while afternoon shift balls averaged 2.8mm, both within the 3.0mm tolerance but clearly separated. Investigation traced the difference to room temperature affecting bladder pre-stretch before panel application. The data from the FH-1352-01 provided the evidence needed to identify and control this process variable before it produced out-of-specification product.

A football (soccer) manufacturer preparing FIFA Quality Programme submissions pre-tested 20 balls per batch on the FH-1352-01 before shipping to the FIFA test laboratory, catching one batch where 4 of 20 balls showed maximum radius differences above the FIFA sphericity tolerance. Investigation identified a seam tension inconsistency introduced by a new stitching operator — the batch was corrected and re-tested before FIFA submission, avoiding a failed approval test and its associated resubmission delay.

A sports ball testing laboratory conducting incoming inspection for a major retailer tested 10 balls from each consignment of imported volleyballs using the FH-1352-01's 8-panel 32-point configuration. One consignment showed a bimodal roundness distribution — five balls within specification and five with maximum radius differences 40–60% above the limit — consistent with mixed production batches or underpressure storage during shipping. The consignment was held pending supplier investigation.

FAQs for the FH-1352-01

What ball sports does the FH-1352-01 cover?

Basketball, football (soccer), volleyball, and handball — the four major inflated panel-construction ball sports with roundness requirements under GB/T 14625.1 and international governing body equipment specifications.

Why are different numbers of sampling points used for different ball constructions?

Each panel configuration has a different seam pattern that maps differently onto the sphere surface. The sampling point count and distribution for each configuration (32 for 8-panel, 40 for 18-panel, 30 for 32-panel) are calibrated to ensure full surface coverage — sampling both seam regions and panel centers — for that specific construction geometry.

What is the difference between average circumference and maximum radius difference?

Average circumference is the mean circumference calculated from all sampled radius values — equivalent to the circumference a tape measure would give if it perfectly integrated over the full surface. Maximum radius difference is the range of sampled radius values (largest minus smallest) — the direct measure of how much the ball deviates from a perfect sphere. GB/T 14625.1 uses maximum radius difference as the roundness metric; international governing bodies (FIBA, FIFA, FIVB) typically specify circumference variation limits, which are mathematically equivalent.

Why is clamping force held below 7N?

Sports balls are pressurized elastic structures. Clamping force above the local deformation threshold causes the ball surface to indent at the clamp contact points, artificially increasing the measured radius at those points and inflating the maximum radius difference result. At <7N, the clamp holds the ball securely without measurable local deformation.

How does 3D multi-point measurement differ from circumference tape measurement?

A tape gives one circumference at one great circle. The FH-1352-01 gives 30–40 radius measurements distributed across the full sphere in three dimensions. A ball can pass a single-circumference tape check while being detectably oblate or irregular in the perpendicular plane — 3D multi-point measurement is the only method that gives a complete roundness picture.

What is the probe repeatability and why does it matter?

Probe repeatability is 0.02mm — repeated measurements of the same ball point give values within 0.02mm of each other. This bounds the random measurement uncertainty that determines whether borderline balls are classified consistently as pass or fail. At 0.02mm repeatability, a ball whose true maximum radius difference is 0.10mm below the rejection limit will be classified correctly on virtually every measurement.

Does the machine automatically select the sampling pattern for the ball type?

The operator selects the ball configuration (8-panel / 18-panel / 32-panel) on the HMI. The PLC then automatically executes the correct sampling sequence — the operator does not manually position the probe at each of 30–40 points.

Related Testing Equipment

• Ball Rebound Height Test Machine (FH-1389) — rebound height testing for basketball, football, volleyball, and handball per FIBA, FIFA, FIVB, and GB/T 14625; pairs with FH-1352-01 for complete ball physical property QC

• Ball Circumference Measurement Equipment — single-meridian circumference verification as a rapid screening tool alongside 3D roundness measurement

• Ball Weight / Mass Scale — mass verification per FIBA, FIFA, FIVB, and IHF specification

• Ball Pressure Gauge and Inflation Equipment — sets and verifies inflation pressure before roundness and rebound testing

• Ball Impact / Drop Test Machine — structural integrity and bladder retention testing under impact loads
