The 5-Axis CNC Racket Drilling Machine is a high-efficiency automated solution designed for drilling and milling holes in badminton rackets, tennis rackets, squash rackets, beach tennis rackets, and pickleball paddles. Equipped with an advanced computer-controlled 5-axis system, the machine allows operators to directly import drilling patterns and dimensions, eliminating the need for complex mold changes when switching between racket models.
Each racket design can be stored as an individual machining program, enabling rapid product changeovers and significantly improving production efficiency. The machine utilizes a proprietary quick-positioning fixture system that securely clamps the racket frame within 1–2 seconds, ensuring high accuracy and repeatability.
A high-speed spindle operating at up to 24,000 RPM delivers clean, burr-free holes while protecting the racket surface from paint damage and decal peeling. Intelligent drilling speed control automatically slows the tool as it approaches the frame surface and accelerates after penetration, maximizing both quality and productivity.
Key Features:
• Advanced 5-axis CNC control system
• Direct import of racket drilling patterns and dimensions
• Program storage for multiple racket models
• Quick-change fixture design for rapid setup
• Automatic tool calibration function
• High-speed spindle up to 24,000 RPM
• Burr-free drilling and milling performance
• Intelligent feed-rate control protects painted surfaces
• One operator can manage 3–4 machines simultaneously
• Suitable for carbon fiber and composite racket frames
• Supports badminton, tennis, squash, beach tennis, and pickleball rackets
Performance Advantages:
• Average machining cycle: 60–70 seconds per racket
• Optional dual-head configuration for increased productivity
• Fixture loading/unloading in approximately 5 seconds
• Positioning accuracy up to 0.02–0.1 mm
• Low labor requirements and easy operation
• High repeatability and production consistency
Applications:
• Badminton racket manufacturing
• Tennis racket production
• Pickleball paddle manufacturing
• Squash racket processing
• Beach tennis racket production
• Composite sports equipment machining
Technical Specifications:
Axis Configuration: 5 Axis
Number of Drill Heads: 1–5
Ball Screw: 20 × 5 mm
Drive Motor: Stepper Motor or Servo Motor (optional)
Linear Guide Rail: 15 mm
Positioning Accuracy: 0.05–0.1 mm
Spindle Motor Power: 2.2 kW
Working Travel:
• X/Y/Z: 300 × 300 × 300 mm
• Optional: 750 × 300 × 300 mm
Machine Structure: Vertical Type
Power Supply: AC 220V
Control System:
• CNC computerized control
• Human-machine interface (HMI)
• Program storage and editing functions
• Automatic tool setting and calibration
Benefits:
This machine significantly reduces labor costs, shortens production cycles, improves drilling quality, and increases manufacturing flexibility. It is an ideal solution for racket manufacturers seeking high precision, high throughput, and fast model changeover capabilities.
