Technical Parameters:
Type
Positive pressure
Pressure range
10～100kpa
Pressure difference sensor
Measuring range:±100pa
Accuracy：±0.2％
Resolution ratio：1pa
Number of channels
1 set of product settings parameter saving
IO Port
3 Input signals / 5 Output signals
Time description
Minimum value（S）
Time air inflation
0.2
Time balance
0.1
Time detection
Time air-out
Display
3.7 inch text display
Product dimension
350*240*350,440*360*670(mm)
Weight
About 10kg
Power
AC220V，50Hz，about 220W
Test pressure source
Using a clean air source with high flow and pressure,
Connect a stable air pressure source adjusted by the pressure regulating valve.
Ambient temperature & humidity
The operating temperature is 5-40 ℃.
The storage temperature is -20~70 ℃.
Below 80% HR, but without condensation.
